FRMQ-980III
Hualian
Bags
Seal
Description
FRM-980 series is available in four models: horizontal model (FRM-980I), vertical model (FRM-980II), floor-standing model (FRM-980III), and floor-standing model with aerating function (FRMQ-980III).FRMC-980III with the function of exhausting. The machine can seal all kinds of heat-sealable materials, which adopts a constant temperature control system and step-less speed adjusting transmission mechanism. The machine works with a solid-ink coder to print the colored labels while sealing. The coder is able to print at high speed with instant dry and highly legible letters that have good adhesion properties. The printing wheel in the machine can be used for both R arrange and T arrange of types. For types in R arrange, the machine can print two lines in font size two (18PT) or three lines in font size five (10.5PT).
Features:
√Reliable performance
√Simple operation
√Convenient maintenance
√Wide range of application
√Constant temperature control system
√Stepless speed regulation
√With printing function
√Various color ink wheels are selectable
√Counting device is optional
√The function of aerating
Application:
1. FRM-980 series plastic film bag continuous sealing machine is suitable for sealing all kinds of heat-sealed packages continuously. Such as PE bag, accordion bag, aluminum foil bag, kraft paper bag, electrostatic bag, Yin-Yang bag.
2. It widely use in the food, pharmaceutical industry, chemical industry, agriculture, lubricating oil, and other industries.
3. To use in the place where there is a restriction on space, such as small factory, monopolization shop, and workshop, etc.
Parameters
MODEL | FRMQ-980III |
Voltage (V/Hz) | AC 220/50 110/60 |
Suction Pump Power(W) | 185 |
Moter Power (W) | 50 |
Sealing Power (W) | 300×2 |
Printing Heating Power (W) | 40×2 |
Speed (m/min) | 0-12 |
Sealing Width (mm) | 10 |
Temperature Range (℃) | 0-300 |
Printing Type | Solid-Ink Roller |
Distance from Sealing Center to Conveyor Table (mm) | 20-40 |
Conveyor Table Size (L × W) (mm) | 954×153 |
Net Weight (kg) | 50 |
Overall Conveyor Loading (kg) | ≤10 |
External Dimensions (L × W × H) (mm) | 1050×900×900 |
Diameter of nozzle for air flushing source | 8mm |
Dimension
Product Detail
Video
