HCS-55AW
Hualian
Cartons
Carton sealer
Product Description
Description
HCS-55AW Pneumatic Random Eco-Friendly Water-actived Tape Carton Sealing Machine uses water active tape to seal the box, green, economic, fast, easy to adjust. Mainly suitable for carton sealing packaging, can not only single operation, also can be used with the assembly line.
1. Pneumatically adapt to various carton sizes, it have two mode:
1) Semi-automatic mode: With locking function, single specification carton sealing efficiency is higher.
2) Fully automatic mode: Adaptive sealing of cartons of different specifications,without manual adjustment.
2. High Speed: Fast sealing speed 20m/min
3. Applicable tape width 48-75mm | Maximum tape diameter 420mm | Tape length 48~90mm adjustable
4. Touch screen control, you can choose to turn off or on the upper and lower sealing functions
5. Use water-activated wet kraft paper, the packaging material is green and environmentally friendly
6. The glue with heating function dissolves faster and the sealing is more stable
Parameters
MODLE | HCS-55AW |
Voltage(V/Hz) | AC 220/50 110V/60 |
Gross Power（W） | 600 |
Max.Carton for Sealing(L*W*H)(mm) | ∞*500*500 |
Min.Carton for Sealing(L*W*H)(mm) | 170*170*130 mm |
Transport Speed (M/MIN) | 20(around 15 boxes/min) |
Material for Tape | Water-activated kraft Paper (Max Dia.420mm) |
Table Height(mm) | 720~890 |
Tape Specification (mm) | 48~75 |
The Length Of Head Tape (mm) | 45~90 |
Power Supply(MPa) | 0.5 |
External Dimension(L*W*H)(mm) | 1510*1115*(1970-2090) |
Net Weight (kg) | 299 |
