Description
CXJ-6040C Automatic Case Erector automatically complete carton erecting, rectangle forming, bottom flaps folding and tape sealing. Easily adjusted for application to cartons in different sizes. Vertical storage,cartons can be added at any time without stopping the machine. By efficiently and consistently erecting carton, automatic packing equipment can provide increased production and labor savings.
Features:
√Stable performance and long life-using
√Simple operation
√Convenient maintenance
√Steel and stainless steel both types
√Cutter Safety system
√Advanced photoelectricity induction control system
√Available for production line
Application:
1. CXJ-C Series Automatic Case Erector automatically complete carton erecting, rectangle forming, bottom flaps folding and tape sealing. Opening carton by vacuum sucker. With alarm function for the lack of adhesive tape & carton.
2. It's widely used in the fields of domestic electrical appliance, foodstuffs, general merchandise, medicine and chemical industry.
3. To use in the place where there is enough space, such as factory and warehouse, etc.
Parameters
Model | CXJ-6040C | |||||
Voltage (V/Hz) | AC 380/50 3 phase | |||||
Power(W) | 800 | |||||
Air supply pressure (Kpa) | 0.5-0.6 | |||||
Capacity (case/min.) | ≤8 | |||||
Case dimensions (mm) | A | B | C | D | E | F |
Min. (mm) | 350 | 250 | 250 | 600 | 230 | 500 |
Max. (mm) | 600 | 400 | 400 | 1000 | 650 | 800 |
Height of vacuum device (mm) | 800+(0-30) | |||||
Applicable tape type | BOPP, PVC, Kraft adhesive tape | |||||
Applicable tape size (mm) | Tape roll dia. ≤350, tape width 48 or 60(standard) or 76 | |||||
External size (L×W×H)(mm) | 2650×2400×1800 | |||||
Weight (kg) | 550 | |||||
Note: The dimension A and B must be different. | ||||||
