Description
The mini-doypack packaging machine GDD-1-300 is characterized in compact structure and easy operation. This series adopt bag magazine at the top which is adjustable. It enables one single machine to satisfy the packaging demand of various bag shapes and sizes. Adopt PLC control, driven by cylinder, low error rate and easy maintenance. Equipped with a variety of electric induction components to ensure smooth operation and accurate packing. Equipped with vacuum pump for vacuuming function.
Features:
√Stable performance and long life-using
√Simple operation
√Convenient maintenance
√PLC control
√Compact single station
√Available for production line
Application:
1. GDD-1-300 mini-doy packaging machine is ideal for Ideal for various applications which are suitable for any type of pre-made pouches. It is suitable for different width of products and different sizes of bags.
2. It's ideal for a lot of applications such as coffee, frozen foods, cookies, cereals, nuts, flowers, candy, etc.
3. To use in the place where there is enough space, such as factory and warehouse, etc.
Parameters
| Model | GDD-1-300 | GDD-1-300 | GDD-1-300 |
| Voltage (V/Hz) | AC 220/50 | AC 220/50 | AC 220/50 |
| Sealing power (w) | 500 | 500 | 500 |
| Packing speed(bag/min) | 6-15 | 5-8 | 6-15 |
| Temperature range(℃ ) | 0-300 | 0-300 | 0-300 |
| Air Source Pressure (Mpa) | 0.65 | 0.65 | 0.65 |
| Seal Width (mm) | 10 | 10 | 10 |
| Suitable bag type | Three side sealing 、Doypack (without zipper) | Doypack (with zipper) | Accordion bag (M fold bag) |
| Bag Size (mm) | 100≤width≤300,100≤length≤430 | 100≤width≤300,100≤length≤430 | 80≤width≤300,100≤length≤430 |
| Dimensions(L*W*H)(mm) | 1827×676×1611 | 1827×676×1656 | 1827×676×1611 |
| Net weight(kg) | 315 | 315 | 315 |
