Semi Automatic Sleeve Sealing Machine For PE Film With CE BSF-6540XLT

Availability:
Quantity:
  • BSF-6540XLT

  • Hualian

  • Bags

Description

BSF-6540XLT semiautomatic sleeve sealing machine can be fed manually or pneumatically. When the sealing & cutting cycle is complete, the product is discharged into the shrink tunnel automatically.



Features:

The machine is used to shrink package single and multiple products.

Sealing and cutting mechanism and shrinking parts are integrated structure saving space required for operation and storage

The simple design enables quick and easy change of packing products with different package sizes.



Application:

1. BSF-6540XLT semiautomatic sleeve sealing machine is applied to heat shrinkable film such as PE、PVC etc.

2. The machine is used for many industries, such as printing, pharmacy, floor, chinaware, beverage, beer, etc.

3. To use in place where there is enough space, such as factory, and warehouse etc.


Parameters

MODELBSF-6540XLT
Voltage (V/Hz)AC 380/50   220/60 3 Phase
Compressed Air (Lt/min)60
Power (kw)18.5
Max. Packing Size (L×W×H) (mm)520×320×350
Maximum Film Width (mm)600
Packing Speed (pcs/min)8-10
Sealing & Cutting Length (mm)650
Sealing Time Setting (S)1.5-3
Temperature Setting (℃)150-250
Suitable Film Thickness (μm)PE 40-80
Tunnel Size (L×W×H) (mm)1500×600×400
External Dimension (L×W×H) (mm)3500×860×2000
Net Weight (kg)520


Product Detail

5 局部图上框BSF-6540XLT细节图


热缩封切机包装样品图


9 产品包装
