HVB-1020F/2
Hualian
Bags
Vacuum
Description
HVB series automatic continuous vacuum packaging machine is specially designed for vacuum packaging needs for massive products The products after packing can be prevented from oxidation, going mould, insects or getting damp, thus can be kept fresh for long storage.
Features:
√Reliable performance
√Intuitive operation
√Convenient maintenance
√Equipped with casters for transportation.
√PLC automatic control system
√Two seal bars for each vacuum circle
√Adjustable conveyor height
Application:
1. HVB series automatic continuous vacuum packaging machine is suitable for vacuum sealing all kinds of heat-sealed packages. Such as PE bag, aluminum foil bag, M fold bag, and reticulated bag, etc.
2. It can perform high speed vacuum packaging with automatic control system
3. The height of the conveyor could be adjusted to meet products with liquid so as to avoid spoil of the liquid.
Parameters
Model | HVB-1020F∕2 |
Voltage (V/Hz) | AC 380/50 220/60 |
Motor power (W) | 550+370 |
Sealing Power (W) | 2000 |
Ultimate Vacuum Pressure (Kpa) | 1 |
Cooling Type | water-cooling |
Sealing Length (mm) | 1020 |
Sealing Width (mm) | 10 or 2×3 |
Capacity(Times/min) | 3-5 |
Chamber Dimension (L×W×H) (mm) | 1100×500×100 |
External Dimensions (L×W×H) (mm) | 1770×1580×1160 |
Applied bag length(mm) | ≤190 |
Net Weight (Kg) | Approx.620 |
